Parker P2FCB448 Solenoid Coil 24 Vdc IP65 Class F

Product Description

The PARKER P2FCB448 is a 24 VDC solenoid coil rated at 6.0 watts with a Class F insulation rating and an IP65 enclosure rating for protection against dust ingress and low-pressure water jets. It is designed for use with Parker B Series Viking valves in fluid control applications where reliable electromagnetic actuation is required. The IP65 enclosure makes it suitable for installations exposed to wash-down conditions or wet environments. Licensed HVAC technicians, plumbers, and fluid system mechanics are the primary trades who service and replace this coil. The coil weighs 0.5 pounds and is sold as a single unit.

This solenoid coil is intended for use with Parker B Series Viking valves in industrial, commercial, and mechanical system applications. It operates reliably across a wide temperature range, from -40 degrees F equivalent cold-temperature environments up to 60 degrees C, making it suitable for both indoor and outdoor installations where ambient temperature swings are a factor. It is well suited for process control, refrigeration, and fluid handling systems that require a compact, weatherproof solenoid coil rated for direct current operation.

Key Features

• 24 VDC operating voltage for low-voltage control circuit compatibility
• 6.0 watt power draw for efficient, low-heat operation
• Class F insulation rating for higher thermal tolerance in demanding applications
• IP65 enclosure rating provides protection against dust and water spray
• Wide operating temperature range: -40 degrees C minimum to 60 degrees C maximum
• Designed specifically for Parker B Series Viking valves

Compatibility

Designed for use with Parker B Series Viking valves as stated by the manufacturer. Verify valve series and coil form factor against your specific valve body before installation.

Installation Notes

Installation should be performed by a qualified technician familiar with low-voltage solenoid valve systems. De-energize the control circuit and isolate the valve from system pressure before removing or installing the coil. Ensure the coil form factor and termination type match the valve body before seating the coil. Refer to applicable local codes and the Parker valve installation guide for torque and wiring requirements.
