Parker P2FCA447 Solenoid Valve Normally Closed 12V

Product Description

The PARKER P2FCA447 is a direct-acting, normally closed solenoid valve designed for precise fluid control in industrial and process applications. Built with a thermoplastic body and FKM fluorocarbon seals, it handles operating pressures from 22 psi up to 232 psi and tolerates media temperatures up to 158 degrees F. The valve operates on 12 volts DC and features a Class F coil with an ISO 4400 Form A 20 mm square 3-pin coil lead connection. It carries an IP 65 enclosure rating, making it suitable for environments where dust and water contact are a concern. Licensed technicians and industrial service professionals are the typical installers for this valve type.

The P2FCA447 is noted for use with the Parker Viking Xtreme Valve platform, making it relevant for installations where that valve series is already deployed. Direct-acting construction means the valve does not rely on a pressure differential to open or close, which is useful in low-pressure or zero-pressure-differential scenarios. The IP 65 rating and FKM seal material support use in moderately aggressive fluid and environmental conditions. This valve ships as a single unit and is well suited to OEM equipment builds, replacement service work, and process control panel assembly.

Key Features

• Direct-acting, normally closed operation — closes when de-energized, no pressure differential required
• Thermoplastic body construction for corrosion resistance in fluid handling applications
• FKM fluorocarbon seal material for compatibility with a broad range of media
• 12 volt DC coil with Class F insulation rating
• ISO 4400 Form A 20 mm square 3-pin coil lead for standardized electrical connection
• IP 65 enclosure rating for resistance to dust ingress and low-pressure water contact

Compatibility

Specified for use with the Parker Viking Xtreme Valve. Verify coil lead connector type and voltage requirements against the target system before ordering.

Installation Notes

Installation should be performed by a qualified technician familiar with fluid control systems and applicable local codes. De-energize and depressurize the system fully before removing or installing the valve. Confirm media compatibility with both the thermoplastic body and FKM seals prior to installation. Ensure the coil lead connection matches ISO 4400 Form A requirements at the panel or controller side.
