Parker Hannifin 76737 Denison Hydraulics T6ED Double Vane Pump & Valve Repair Kit

Product Description

The Parker Hannifin 76737 includes a Denison Hydraulics T6ED series double vane pump suitable for industrial applications. This pump operates in a fixed displacement mode and features a standard drivetrain. It provides a total displacement of two hundred ninety-four point three milliliters per revolution at speeds reaching up to two thousand two hundred rpm. The rotation is counter-clockwise. It has an SAE-C two-bolt J744c mounting interface, a splined shaft (SAE C) fourteen teeth, and Buna N seals.

• Designed for industrial applications
• Total displacement of two hundred ninety-four point three milliliters per revolution
• Includes SAE 4-bolt J518 porting connections

Product Highlights

This pump is robust and efficient for various industrial settings, ensuring reliable operation.

Product Information

Standard Information

• Type: Double Vane Pump
• Model: T6ED

Technical Specifications

• Application: Industrial
• Mode: Fixed Displacement
• Drivetrain: Standard Drive
• Displacement: 294.3 ml/rev
• Speed: up to 2200 rpm
• Direction of Rotation: Left (counter-clockwise)
• Mounting Interface: SAE-C 2-bolt J744c
• Type of Shaft: splined (SAE C) 14T
• Seal Class: Buna N
• Pump Section 'P1': 183.3 ml/rev
• Pump Section 'P2': 111.0 ml/rev
• Porting Connections: SAE 4-bolt J518
• Fixing Screws: UNC thread
• Condition: New
