Parker DT-1000-MFMF-65 Hydraulic Check Valve 75 Gpm

Product Description

The PARKER DT-1000-MFMF-65 is a hydraulic control check valve engineered for inline flow control in high-pressure hydraulic systems. It allows flow in one direction and prevents backflow, protecting pumps, actuators, and downstream components from pressure reversal. The valve features a 1-5/16-12 Male JIC inlet thread, a maximum flow rate of 75 GPM, and a maximum working pressure of 3,000 psi. The steel body with metal seals makes it well suited for demanding industrial and mobile hydraulic applications. Licensed hydraulic technicians and fluid power specialists are the typical installers.

This check valve is designed for use in mobile equipment, industrial machinery, and other hydraulic circuit applications where reliable one-way flow control is required. The Male JIC thread standard is common across a wide range of hydraulic plumbing configurations. At 2.44 inches overall length and 1.5 inches in both width and height, the DT-1000-MFMF-65 fits into compact hydraulic manifold and inline installations where space is a consideration.

Key Features

• Maximum flow rate of 75 GPM supports high-volume hydraulic circuits
• Rated to 3,000 psi maximum working pressure for demanding system loads
• 1-5/16-12 Male JIC inlet thread for broad hydraulic plumbing compatibility
• Steel body construction provides durability in harsh operating environments
• Metal seal design suitable for high-pressure, high-cycle applications
• Compact profile at 2.44 inches length and 1.5 inches width and height

Compatibility

Designed as an OEM-style replacement or service component for hydraulic systems requiring a 1-5/16-12 Male JIC inline check valve rated at 75 GPM and 3,000 psi.

Installation Notes

Installation should be performed by a qualified fluid power technician or hydraulic systems specialist. Depressurize and isolate the hydraulic circuit fully before removing or installing any valve. Verify thread engagement and torque connections to the fitting manufacturer specifications using calibrated tools. Inspect all adjacent fittings and lines for wear or contamination before returning the system to service.
