Parker BVHP06SSS1N Ball Valve 3/8 Inch Sae 6000 Psi

Product Description

The PARKER BVHP06SSS1N is a standard manual ball valve designed for high-pressure hydraulic and fluid power applications. It features a 3/8-inch pipe size with SAE x SAE end connections and a lever handle for straightforward quarter-turn on/off control. Rated to a maximum working pressure of 6000 psi (414 bar), this valve is built with a carbon steel body and trim, paired with a Delrin seal for reliable shutoff performance. Licensed HVAC technicians, hydraulic system installers, and industrial pipe fitters install this valve where dependable manual isolation is required in demanding pressure environments.

This ball valve is suited for use in hydraulic lines, fluid power circuits, and related industrial piping systems where high-pressure manual shutoff is needed. The SAE x SAE thread connection (9/16-18) makes it compatible with standard SAE hydraulic fittings commonly found in mobile equipment, industrial machinery, and stationary hydraulic power units. Its compact lever-handle design allows for quick visual confirmation of valve position in tight service spaces.

Key Features

• Maximum working pressure of 6000 psi (414 bar) for demanding hydraulic applications
• Carbon steel body and trim provide durability in high-pressure service
• SAE x SAE end connections with 9/16-18 thread size for standard hydraulic fitting compatibility
• Lever handle enables fast quarter-turn operation and clear open/closed indication
• Delrin seal material delivers consistent, low-friction shutoff performance

Compatibility

Designed as an OEM-style replacement or new-installation manual ball valve for hydraulic and fluid power systems utilizing SAE straight-thread connections at 3/8-inch pipe size.

Installation Notes

Installation should be performed by a qualified hydraulic technician or licensed pipefitter. Depressurize and fully drain the hydraulic circuit before removing or installing any valve. Ensure SAE thread engagement is correct and torque fittings per the system manufacturer's fitting specifications. Verify that fluid compatibility with Delrin seals is confirmed before commissioning in non-hydraulic fluid service.
