Parker BD-1J943-1612-1 Hydraulic Swivel 90 Elbow 3/4 Inch

Product Description

The PARKER BD-1J943-1612-1 is a female Seal-Lok swivel 90-degree elbow fitting designed for hydraulic hose assemblies. Machined from steel, this fitting connects a 3/4-inch hydraulic hose to a Seal-Lok port at a 90-degree angle, redirecting flow in tight or confined plumbing runs. The swivel design allows the hose to be oriented without twisting during assembly and final torquing. This type of fitting is used throughout mobile hydraulic systems, industrial machinery, and fluid power circuits where routing constraints require an angled connection. Installation is typically performed by hydraulic technicians and fluid power specialists.

This fitting is suited for hydraulic circuits requiring a 90-degree directional change at the hose termination point. The Seal-Lok interface uses an O-ring face seal (ORFS) design that provides a leak-resistant connection at the port face, making it appropriate for high-pressure hydraulic systems where thread-only sealing is insufficient. It is compatible with standard 3/4-inch hydraulic hose ends and mates with Seal-Lok or ORFS-style ports found on hydraulic cylinders, valves, pumps, and manifolds in both mobile and stationary equipment.

Key Features

• Female Seal-Lok (ORFS) swivel interface for leak-resistant, face-seal connections
• 90-degree elbow geometry for routing hose in space-constrained installations
• Swivel body allows hose positioning without inducing twist in the assembly
• Steel construction for durability in hydraulic service environments
• Sized for 3/4-inch hydraulic hose

Compatibility

Designed as an OEM-style replacement or new-assembly fitting for 3/4-inch hydraulic hose with Seal-Lok (ORFS) terminations. Mates with Seal-Lok and ORFS-style ports as specified in the input data. Verify port thread size and O-ring seat condition before installation.

Installation Notes

Installation should be performed by a qualified hydraulic technician. Depressurize and bleed down the hydraulic system completely before disconnecting or installing any hose fitting. Inspect the O-ring and sealing face for damage prior to assembly, and replace the O-ring if worn or deformed. Follow the equipment manufacturer and applicable fluid power standards for final assembly torque values appropriate to this fitting size and material.
