Parker 3C24F-F5 Hydraulic Check Valve 125 Gpm

Product Description

The PARKER 3C24F-F5 is a hydraulic control check valve designed to permit flow in one direction while preventing backflow in hydraulic systems. It features a 1-1/2-11-1/2 female NPTF inlet and a maximum flow rate of 125 GPM. The fluorocarbon seals provide reliable performance across a wide temperature range, from -15 degrees F to 400 degrees F. Overall dimensions are 6.5 inches in length, 2.5 inches in width, and 6.51 inches in height. This valve is installed by licensed hydraulic and fluid-power technicians on industrial and commercial equipment lines.

This check valve is suited for hydraulic circuits in industrial machinery, mobile equipment, and fluid-power systems where backflow prevention is critical. The female NPTF thread standard ensures a pressure-tight, dryseal connection without the need for additional sealant on most installations. Applications include hydraulic power units, cylinder circuits, and pump outlet lines where flow direction must be strictly controlled. The 125 GPM flow capacity covers a broad range of mid- to high-volume hydraulic circuit requirements.

Key Features

• Maximum flow rate of 125 GPM supports mid- to high-volume hydraulic circuits
• 1-1/2-11-1/2 female NPTF inlet provides a pressure-tight dryseal thread connection
• Fluorocarbon seals rated from -15 degrees F to 400 degrees F for high-temperature hydraulic fluid compatibility
• Compact form factor at 6.5 inches overall length and 6.51 inches overall height
• One-directional flow control prevents backflow and protects upstream components

Compatibility

Designed as an OEM-style replacement or direct-fit check valve for hydraulic systems using 1-1/2-11-1/2 female NPTF connections and requiring up to 125 GPM flow capacity.

Installation Notes

Installation should be performed by a qualified hydraulic or fluid-power technician. Depressurize and isolate the hydraulic circuit completely before removing or installing any valve. Verify that the system fluid is compatible with fluorocarbon seals before installation. Follow applicable industry standards and equipment manufacturer procedures for hydraulic line connections and system startup.
