Parker 2A-C2L-1-BN-B Check Valve 1/8 in Compression Brass

Product Description

The PARKER 2A-C2L-1-BN-B is an inline check valve designed to allow one-directional fluid or gas flow while preventing backflow in pressurized piping systems. It features a brass body with a stainless steel spring mechanism and connects via compression fittings on both ends. Rated at 3,000 WOG (Water, Oil, Gas), this valve is built for demanding service conditions. With a 1/8 inch pipe size, it fits into compact line configurations where space and pressure integrity both matter. Plumbers, pipefitters, and HVAC technicians install this type of valve in refrigerant, pneumatic, hydraulic, and fluid distribution lines.

This check valve is suited for residential and light commercial applications where a reliable, low-profile inline backflow prevention component is required. The compression x compression end connection makes it compatible with standard tubing installations without soldering or threading. Typical install scenarios include instrument tubing, small-bore hydraulic circuits, pneumatic control lines, and similar compressed-fluid or gas distribution systems where preventing reverse flow is critical to system integrity.

Key Features

• Inline configuration allows direct installation into existing tubing runs
• Compression x compression end connections eliminate the need for soldering or pipe threading
• Brass body provides corrosion resistance suitable for water, oil, and gas service
• Stainless steel spring ensures consistent cracking pressure and long service life
• 3,000 WOG pressure rating supports high-pressure system applications
• 1/8 inch pipe size fits compact instrumentation and control line installations

Compatibility

Designed as an OEM-style inline check valve for 1/8 inch compression tube fittings in water, oil, and gas service applications.

Installation Notes

Installation is typically performed by a licensed plumber, pipefitter, or HVAC technician. Depressurize and isolate the line completely before removing any existing fittings or installing this valve. Ensure tubing ends are cut cleanly and deburred before seating into compression fittings to maintain a leak-free joint. Follow applicable codes such as the IPC or IFGC for fluid and gas line service requirements.
