Parker 2.00TE4MA2UV14ZA05.00 Rodless Air Cylinder

Product Description

The PARKER 2.00TE4MA2UV14ZA05.00 is a double acting rodless air cylinder designed for linear motion applications in industrial pneumatic systems. It features a 2 inch bore and a 5 inch stroke, with a maximum working pressure rating of 250 psi. The aluminum body keeps weight low while maintaining structural rigidity. An overall length of 5.625 inches and an overall width of 2.5 inches make this a compact option for tight mounting envelopes. Fluorocarbon seals provide resistance to a wide range of media and temperatures. This cylinder is installed and serviced by industrial maintenance technicians and pneumatic system integrators.

This rodless air cylinder is suited for linear transfer, pick-and-place, and positioning applications where a conventional rod-style cylinder would require excessive space. The basic mount style allows for flexible integration into machine frames and custom fixtures. The 3/8 NPTF port accepts standard threaded pneumatic fittings for straightforward plumbing into compressed air circuits. Typical installations are found in light to medium-duty industrial automation, assembly equipment, and material handling systems operating on plant-supplied compressed air.

Key Features

• Double acting operation provides powered movement in both extend and retract directions
• 2 inch bore with 5 inch stroke delivers balanced force output across a compact travel range
• 250 psi maximum working pressure compatible with standard industrial compressed air systems
• Aluminum body construction reduces overall assembly weight
• Fluorocarbon seals offer broad chemical and temperature resistance
• 3/8 NPTF port size accommodates common pneumatic fittings without adapters
• Basic mount style supports versatile fixture and frame integration

Compatibility

Designed as an OEM-style replacement or direct installation component for industrial pneumatic systems requiring a double acting rodless air cylinder with a 2 inch bore, 5 inch stroke, and 3/8 NPTF porting at up to 250 psi.

Installation Notes

Installation should be performed by a qualified industrial maintenance technician or pneumatic systems integrator. Depressurize and lock out the compressed air supply before mounting, connecting fittings, or performing any service on the cylinder. Ensure all port connections are sealed with appropriate thread sealant compatible with pneumatic service. Verify that the system operating pressure does not exceed the 250 psi rated maximum before returning to service.
