Parker 1795HB-16-12 Brass Elbow Hose Barb Fitting

Product Description

The PARKER 1795HB-16-12 is a brass elbow barbed hose fitting that connects a 1-inch ID hose to a 1-1/16-12 SAE straight thread port. The elbow configuration routes fluid lines at a 90-degree angle, reducing stress on hose assemblies in tight or angled installations. Constructed from brass, this fitting offers solid corrosion resistance for hydraulic, coolant, and fluid transfer applications. The beaded hose barb design provides a secure mechanical grip on the hose end, and the SAE straight thread connection seals reliably against mating ports. Rated from -40 degrees F to 160 degrees F, it suits a wide range of operating conditions encountered in industrial and mobile equipment service.

This fitting is used in hydraulic and fluid transfer systems where a hose must terminate at a threaded SAE straight thread port with a directional change. Typical installations include mobile hydraulic equipment, industrial machinery, and cooling or lubrication circuits. The elbow orientation is useful in confined equipment bays where a straight fitting would create unwanted hose bend or kink. Licensed plumbers, hydraulic technicians, and industrial maintenance mechanics are the primary installers. The 1-inch ID hose barb and 1.25-inch hex head size allow standard wrench engagement during assembly.

Key Features

• Beaded hose barb provides positive retention on 1-inch ID hose without requiring a separate crimp sleeve
• Brass construction resists corrosion in hydraulic fluid, water, and coolant service
• SAE straight thread end seals against a mating port without relying on thread deformation
• Elbow body routes hose at a directional change to reduce hose strain in tight installations
• Operating temperature range of -40 degrees F to 160 degrees F covers most industrial and mobile equipment environments
• 1.25-inch hex head allows standard wrench engagement for torque control on installation

Compatibility

Designed for use with 1-inch ID hose assemblies terminating at 1-1/16-12 SAE straight thread ports on hydraulic systems, cooling circuits, and fluid transfer equipment.

Installation Notes

Depressurize and drain the hydraulic or fluid circuit completely before removing or installing any fittings. A hydraulic technician or qualified mechanic should perform the installation using an appropriate open-end or combination wrench sized to the 1.25-inch hex. Ensure the hose is fully seated past the bead on the barb before securing with a clamp or fitting collar. Inspect the SAE straight thread port for damage or debris before installation, as a clean seating surface is required for a leak-free connection.
