Parker 1795HB-10-8 Brass Barbed Hose Elbow 5/8 Id

Product Description

The PARKER 1795HB-10-8 is a brass elbow barbed hose fitting designed to connect a 5/8 inch ID hose to a 3/4-16 SAE straight thread port. The elbow configuration redirects flow at a 90-degree angle, making it a practical solution where space or routing constraints prevent a straight fitting. Constructed from brass, it offers solid corrosion resistance in hydraulic, pneumatic, and fluid transfer applications. The beaded hose barb design provides a more secure grip on the hose, reducing the risk of blowoff under pressure. Licensed plumbers, HVAC technicians, and fluid system installers commonly use this fitting during equipment assembly and service work.

This fitting is suited for use in low-to-medium pressure fluid systems found in residential and light commercial equipment. Typical applications include hydraulic hose assemblies, coolant lines, and general-purpose fluid transfer circuits where a threaded port to barbed hose transition is required. The 3/4-16 SAE straight thread end mates with standardized port bosses common in fluid power and HVAC equipment. The 5/8 inch barb end accepts standard 5/8 inch ID flexible hose. Operating temperature range spans -40 degrees F to 160 degrees F, covering most ambient and fluid-temperature conditions in these applications.

Key Features

• Elbow configuration with beaded hose barb for secure hose retention
• Brass construction for corrosion resistance in fluid systems
• 3/4-16 SAE straight thread end mates with standard port bosses
• 5/8 inch barb accommodates 5/8 inch ID flexible hose
• Wide operating temperature range: -40 degrees F to 160 degrees F
• 7/8 inch hex head size allows standard wrench installation

Compatibility

Designed as an OEM-style replacement or service fitting for fluid systems using 3/4-16 SAE straight thread ports and 5/8 inch ID hose connections.

Installation Notes

Installation should be performed by a qualified technician familiar with fluid system assembly. Depressurize and drain the system before removing or installing any fittings. Torque the threaded end to the port boss using a wrench on the hex head — do not grip the hose barb. Inspect the hose end for cuts or deformation before seating it over the barb, and secure with an appropriate clamp.
