Parker 15F12EA Coalescing Filter 34 Cfm 1/4 Inch Port

Product Description

The PARKER 15F12EA is a coalescing filter designed to remove oil aerosols, fine particulates, and water mist from compressed air lines. Rated at 34 CFM with a 0.01 micron filtration rating, it delivers clean, dry air to downstream pneumatic equipment, tools, and instrumentation. The polycarbonate bowl provides visual monitoring of collected liquid without disassembly, and the manual drain allows controlled removal of accumulated condensate. At 150 max psi, this filter handles standard industrial compressed air system pressures. Licensed HVAC, mechanical, and industrial technicians install this unit as part of compressed air treatment trains alongside regulators and lubricators.

The 15F12EA suits residential and light commercial compressed air applications where air quality directly affects equipment performance and service life. It is well suited for installation upstream of pneumatic actuators, solenoid valves, spray equipment, and precision air tools. The modular connection design allows it to integrate into multi-unit filtration assemblies without additional fittings, simplifying the construction of filter-regulator-lubricator combinations. The 1/4 inch port size fits standard quarter-inch NPT compressed air plumbing commonly found in light industrial and shop environments.

Key Features

• 0.01 micron filtration rating removes fine oil aerosols and submicron particulates
• 34 CFM flow capacity suits light industrial and shop compressed air systems
• 150 max psi pressure rating covers standard compressed air line pressures
• Polycarbonate bowl allows visual inspection of collected liquid without disassembly
• Manual drain for controlled removal of accumulated condensate
• Modular connection supports multi-unit filter-regulator-lubricator assemblies

Compatibility

Designed as an OEM-style coalescing filter for use in compressed air treatment systems with 1/4 inch NPT ported plumbing and system pressures up to 150 psi.

Installation Notes

Install this filter with airflow direction matching the directional arrow marked on the body. Depressurize and lock out the compressed air system before installation or bowl removal. Use thread sealant appropriate for compressed air service on NPT connections. Manual drain should be serviced regularly to prevent liquid carryover into downstream equipment.
