Parker 12AT103CBPGN12H Hydraulic Filter Assembly 3 Micron

Product Description

The PARKER 12AT103CBPGN12H is a hydraulic filter assembly designed to remove particulate contamination from hydraulic fluid circuits. It uses a 3-micron cellulose filter media to capture fine particles that cause premature wear in pumps, valves, and actuators. The body is constructed from low carbon steel with an aluminum component, and the assembly uses a nitrile seal for fluid compatibility. Rated to 150 psi maximum operating pressure, it handles a wide temperature range from -40 to 225 degrees F. This assembly installs directly in-line via a 3/4 inch NPTF threaded port. It is suited for mobile and stationary hydraulic systems maintained by fluid power technicians and industrial maintenance professionals.

This filter assembly is appropriate for use in low-to-medium pressure hydraulic circuits where fine filtration is required at the 3-micron level. Typical applications include return-line or low-pressure supply-line filtration on industrial machinery, mobile equipment, and hydraulic power units. The 3/4 inch NPT port size makes it compatible with common hydraulic plumbing configurations found in both shop and field installations. It is selected where cellulose media is acceptable and nitrile seal compatibility with the system fluid has been confirmed.

Key Features

• 3-micron cellulose media for fine particulate removal in hydraulic circuits
• Low carbon steel and aluminum body construction for durability and reduced weight
• Nitrile seal material suitable for use with petroleum-based hydraulic fluids
• 3/4 inch NPTF threaded port for direct in-line installation
• Rated to 150 psi maximum operating pressure
• Wide operating temperature range of -40 to 225 degrees F

Compatibility

Designed as an OEM-style replacement or service filter for low-to-medium pressure hydraulic systems using 3/4 inch NPT plumbing and petroleum-based hydraulic fluid compatible with nitrile seals.

Installation Notes

Installation should be performed by a qualified fluid power technician or hydraulic system mechanic. Depressurize and isolate the hydraulic circuit completely before removing any existing filter or fittings. Confirm that system fluid and operating pressure do not exceed the rated 150 psi maximum and that the fluid is compatible with cellulose media and nitrile seals before installation. Apply thread sealant appropriate for hydraulic service to the NPTF threads and torque to the fitting manufacturer's specification for the port size.
