Parker 11643-16-16 Hydraulic Hose Elbow 1 Inch

Product Description

The PARKER 11643-16-16 is a hydraulic hose elbow fitting designed to connect hose assemblies at an angled orientation within high-pressure hydraulic systems. With a hose size of 16 and a hose diameter of 1 inch, this elbow fitting redirects fluid flow without requiring a straight inline connection, reducing stress on hose runs and improving routing flexibility. It is installed by hydraulic system technicians and industrial mechanics working on mobile equipment, industrial machinery, and fluid power circuits. The angled geometry helps manage hose routing in tight spaces where a straight fitting would create excessive bend radius issues.

This elbow fitting is suited for hydraulic plumbing applications in both mobile and stationary equipment. Typical installation scenarios include construction equipment, agricultural machinery, and industrial hydraulic power units where hose routing must accommodate structural obstructions or directional changes. The 1-inch thread size allows connection to standard hydraulic ports and hose ends of the corresponding size, making it a practical fitting for field and shop assembly work alike.

Key Features

• Elbow geometry enables angled hose routing to reduce hose strain and improve layout efficiency
• Hose size 16 with 1-inch hose diameter for compatibility with standard hydraulic hose assemblies
• 1-inch thread size for secure connection to matching hydraulic ports and adapters
• Sold individually, making it suitable for single-fitting replacement or small assembly jobs

Compatibility

Designed as an OEM-style hydraulic elbow fitting for use with -16 hose size hydraulic assemblies requiring a 1-inch hose diameter and 1-inch thread connection.

Installation Notes

Installation should be performed by a qualified hydraulic technician or industrial mechanic familiar with fluid power system assembly. Depressurize and fully relieve hydraulic system pressure before removing or installing any fittings. Use appropriate wrenching flats and avoid over-torquing, which can damage sealing surfaces or threads. Follow applicable fluid power standards and equipment manufacturer specifications during assembly.
