Parker 1.12USU1602.00 Air Cylinder 1-1/8 in Bore 200 Psi

Product Description

The PARKER 1.12USU1602.00 is a double acting rodless air cylinder designed for linear motion control in pneumatic systems. It features a 1-1/8 inch bore, a 2 inch stroke, and a maximum working pressure of 200 psi. The body is constructed from steel, aluminum, and stainless steel, with nitrile butadiene rubber seals for reliable performance across a range of industrial environments. Rodless cylinders conserve space along the stroke axis compared to rod-style cylinders, making this unit well-suited for applications where total assembly length is a constraint. Licensed HVAC, mechanical, and industrial technicians install this type of actuator in automated equipment, machine guarding, and process control systems.

This cylinder is suited for use in factory automation, material handling, and light industrial machinery where a compact double acting actuator is required. The universal mount style allows flexible positioning within the equipment frame. The 1/8 NPTF port accepts standard pneumatic fittings for straightforward integration into existing air circuits. The 3/8 inch rod diameter with a 3/8-24 male rod thread allows direct connection to load-side hardware without adapters in most standard configurations. The unit weighs 1.3 pounds and has an overall length of 4.87 inches.

Key Features

• Double acting design provides controlled force in both extend and retract directions
• 1-1/8 inch bore with 200 psi maximum working pressure
• 2 inch stroke length in a compact 4.87 inch overall body length
• 1/8 NPTF port for compatibility with standard pneumatic fittings
• Stainless steel, steel, and aluminum construction for durability
• Nitrile butadiene rubber seals for resistance to common hydraulic and pneumatic media
• Universal mount style for flexible installation orientation

Compatibility

Designed as an OEM-style replacement or direct-fit pneumatic actuator for industrial equipment requiring a double acting rodless air cylinder with a 1-1/8 inch bore and universal mount configuration.

Installation Notes

Installation should be performed by a qualified pneumatic or mechanical technician. Isolate and depressurize the air supply fully before removing or installing the cylinder. Verify that all port fittings and thread connections are properly torqued per fitting manufacturer specifications and that air supply pressure does not exceed 200 psi. Confirm that the mounting hardware and load attachment are rated for the cylinder output force before returning the system to service.
