Panduit SCS2/0-X Compression Connector 2/0 AWG

Product Description

The PANDUIT SCS2/0-X is a compression connector for 2/0 AWG wire. This standard barrel butt splice is made from tin-plated copper and tested by Telcordia to meet NEBS Level 3 specifications. It features color-coded barrels marked with Panduit die index numbers to ensure proper crimp die selection.

• Tin-Plated
• UL listed and CSA certified
• Non-Insulated

Product Highlights

The PANDUIT SCS2/0-X compression connector is ideal for use with stranded copper conductors.

Product Information

Standard Information

• Brand: PANDUIT
• Manufacturer Part Number: SCS2/0-X
• Country of Origin: Mexico

Technical Specifications

• Item [Specifications]: Compression Connector,2/0 AWG
• Category: Connectors, Interconnects
• Terminals: Wire Splice Connectors
• Termination: Crimp
• Manufacturer: Panduit Corp
• Wire Gauge: 2/0 AWG
• Packaging: Bulk
• Insulation: Non-Insulated
• Part Status: Active
• Terminal Type: Butt Splice, Inline, Individual Openings
• Base Product Number: SCS2
• Number of Wire Entries: 2
• Brand: Pan-Lug
• Finish: Tin-Plated
• Standard: UL listed and CSA certified
• Material: Copper
• Conductor Size: 2/0 AWG
• Lug Wire Size: 2/0 AWG
• Length: 2 in.
• Size: 2/0
• Allowable Gauge Range: 2/0
