Panduit P14-6F-M Fork Terminal 18-14 AWG #6

Product Description

The Panduit P14-6F-M is a fork terminal designed for secure and efficient wire termination. This non-insulated terminal supports 18-14 AWG wire and features a #6 stud size. It is made from high-conductivity electrolytic copper and finished with a corrosion-resistant tin plating, ensuring long-term reliability.

• Brazed Seam
• Serrated Termination
• Non-Insulated

Product Highlights

The PANDUIT P14-6F-M fork terminal ensures fast assembly and dependable performance for a variety of applications.

Product Information

Standard Information

• Brand: PANDUIT
• Manufacturer Part Number: P14-6F-M
• Country of Origin: Mexico

Technical Specifications

• Category: Connectors, Interconnects
• Terminals: Spade Connectors
• Mounting Type: Free Hanging (In-Line)
• Manufacturer: Panduit Corp
• Termination: Crimp
• Series: Pan-Term
• Wire Gauge: 14-18 AWG
• Packaging: Bulk
• Insulation: Non-Insulated
• Part Status: Active
• Features: Brazed Seam, Serrated Termination
• Terminal Type: Standard
• Contact Finish: Tin
• Stud/Tab Size: 6 Stud
• Contact Material: Copper
• Width - Outer Edges: 0.280" (7.11mm)
• Tongue Inside Opening: 0.150" (3.81mm)
• Length - Overall: 0.630" (16.00mm)
• Finish: Tin-Plated
• Standard: UL Listed 587H E52164; CSA Certified LR31212
• Use With: CT-100, CT-1570, CT-2300/ST (CD-570), CT-2500/L (CT-2570CH), UP14ZLW (CD-570)
• Color: Metallic
• Conductor Size: 18-14 AWG
• Stud Size: #6
• Lug Wire Size: 18-14 AWG
• Color Family: Metallic
• Max. Temperature Rating: 302 F
• MPN: P14-6F-M
• Condition: New
