Panduit P14-6F-C Pan-Term Fork Terminal #6

Product Description

The PANDUIT P14-6F-C is a Pan-Term fork terminal designed for secure and reliable connections. This non-insulated terminal accommodates 18-14 AWG wires and is designed for a #6 stud size. It features a tin-plated finish and is constructed from high-conductivity copper. Ideal for various electrical applications requiring a dependable fork-type connection.

• Non-insulated fork terminal
• Accommodates 18-14 AWG wires
• Designed for #6 stud size

Product Highlights

The PANDUIT P14-6F-C provides a reliable solution for creating fork-type connections in electrical systems.

Product Information

Standard Information

• Brand: PANDUIT
• Manufacturer Part Number: P14-6F-C
• Country of Origin: Mexico

Technical Specifications

• Catalog Number: P14-6F-C
• Manufacturer: Panduit
• Brand: Panduit
• Sub Brand: Pan-Term
• Country of Origin: Mexico
• Made in USA: No
• Color: Metallic
• Connection: Standard
• Enclosure: Fork shape
• Finish: Tin-Plated
• Insulation: Non-Insulated
• Material: Copper
• Standard: UL Listed 587H E52164; CSA Certified LR31212
• UPC: 074983805082
• GTIN: 00074983805082
• Item Type: Fork Terminal
• Size: #6
• Temperature Rating: 302 Degrees Fahrenheit (150 Degrees Celsius)
• Voltage Rating: 2000 V
• Wire Size: 14-18 AWG
• IGCC: 4543
• Mounting Type: Free Hanging (In-Line)
• Termination: Crimp
• Series: Pan-Term
• Packaging: Bulk
• Part Status: Obsolete
• Features: Brazed Seam, Serrated Termination
• Terminal Type: Standard
• Contact Finish: Tin
• Stud/Tab Size: 6 Stud
• Contact Material: Copper
• Width - Outer Edges: 0.280" (7.11mm)
• Tongue Inside Opening: 0.150" (3.81mm)
• Length - Overall: 0.630" (16.00mm)
• Base Product Number: P14
• Model: FORK TERMINALS
• MPN: P14-6F-C
• Unit of Measure: EA
