Panduit FZ2ERLNSNSNM009 OM4 Duplex Lc Fiber Patch Cable

Product Description

The PANDUIT FZ2ERLNSNSNM009 is an OM4 duplex fiber optic patch cable designed for high-density data center and enterprise network installations. It features a 2-fiber, 1.6mm diameter construction with LC duplex connectors on both ends and an OFNR (Optical Fiber Nonconductive Riser) jacket rating. OM4 multimode glass supports high-bandwidth applications and is commonly used with 10G, 40G, and 100G transceivers over short-to-medium distances. Network technicians and low-voltage installers rely on this cable type for structured cabling backbone and horizontal runs.

This patch cable is suited for use in commercial and enterprise environments where riser-rated cabling is required by code. Typical installations include data centers, server rooms, telecom closets, and structured cabling systems. The LC duplex form factor is widely used with SFP and SFP+ transceiver modules in switches, routers, and storage equipment. The slim 1.6mm jacket diameter supports high port-density patching in tight cable management environments.

Key Features

• OM4 multimode fiber supports 10G, 40G, and 100G applications
• LC duplex connectors on both ends for SFP and SFP+ compatibility
• 1.6mm slim jacket diameter for high-density patch panel installations
• OFNR jacket rating meets NEC riser installation requirements
• 2-fiber duplex construction for full-duplex data transmission

Compatibility

Designed as an OEM-style replacement and standard-fit patch cable for LC duplex OM4 multimode fiber ports in riser-rated structured cabling systems.

Installation Notes

Installation should be performed by a qualified low-voltage technician or network cabling professional familiar with TIA-568 structured cabling standards. Inspect connector end-faces for contamination before mating and clean with an approved fiber optic cleaning tool if needed. Avoid exceeding the minimum bend radius of the cable during routing to prevent signal loss. Do not route alongside high-voltage conductors without proper separation per applicable NEC guidelines.
