Panduit FZ2ELLNSNSNM046 OM4 Duplex Lc Fiber Patch Cable

Product Description

The PANDUIT FZ2ELLNSNSNM046 is a 2-fiber OM4 duplex fiber optic patch cable designed for high-density structured cabling installations. Built with a 1.6mm jacketed cord, LSZH (Low Smoke Zero Halogen) outer jacket, and LC duplex connectors on both ends, this patch cable supports multimode OM4 transmission for backbone and horizontal fiber runs. The LSZH jacket limits toxic smoke and halogen gas release in the event of fire, making it appropriate for plenum-adjacent or enclosed network environments. Licensed cabling technicians and low-voltage installers deploy this cable in data centers, telecom rooms, and enterprise LAN infrastructures.

This patch cable is suited for multimode OM4 fiber optic networks requiring LC duplex connectivity. Typical applications include switch-to-patch-panel connections, fiber cross-connects, and equipment room jumpers in commercial and enterprise environments. The 1.6mm cordage diameter supports high-density patching in tight cable management trays and high-port-count fiber panels.

Key Features

• OM4 multimode fiber supports high-bandwidth applications including 10G, 40G, and 100G ethernet
• LC duplex connectors on both ends for standard SFP and fiber panel terminations
• 1.6mm jacket diameter suited for high-density cable management environments
• LSZH jacket material reduces toxic emissions in enclosed or poorly ventilated spaces
• 2-fiber duplex configuration supports full-duplex data transmission
• PC (Physical Contact) polish on ferrules for low insertion loss and reliable signal integrity

Compatibility

Designed as an OEM-style replacement and standard patch cable for OM4 multimode fiber optic systems using LC duplex interfaces in structured cabling installations.

Installation Notes

Installation should be performed by a qualified low-voltage cabling technician familiar with fiber optic handling procedures. Always inspect ferrule end-faces with a fiber inspection scope before mating connectors, and clean ferrules using approved fiber cleaning tools prior to insertion. Avoid bending the cable beyond its minimum bend radius, and de-energize connected active equipment at the transceiver level before patching into live fiber ports when laser safety is a concern. Reference TIA-568 standards for structured cabling best practices.
