Panduit FX23RSNSNSNM044 OM3 Duplex Sc Fiber Patch Cable

Product Description

The PANDUIT FX23RSNSNSNM044 is a 2-fiber OM3 multimode duplex fiber optic patch cable featuring SC connectors on both ends and a 3mm outer jacket diameter. Rated OFNR (Optical Fiber Nonconductive Riser), this cable meets riser-rated fire and smoke requirements for vertical runs between floors. It is designed for structured cabling installations in commercial and enterprise environments where high-bandwidth multimode fiber connectivity is required. Licensed low-voltage technicians and data communications installers are the primary trades that handle termination and routing of this assembly.

This patch cable is suited for backbone and horizontal fiber runs in riser-rated applications such as telecommunications rooms, data centers, and campus network installations. The SC duplex configuration makes it compatible with standard fiber switches, transceivers, patch panels, and media converters using SC-style ports. The OM3 designation supports high-speed data transmission at 10 Gigabit Ethernet and similar multimode protocols over appropriate distances.

Key Features

• OM3 multimode fiber classification for 10GbE and high-bandwidth applications
• 2-fiber duplex construction with SC connectors on both ends
• 3mm riser-rated (OFNR) outer jacket for compliant vertical cable routing
• Polished SC connectors for low insertion loss and reliable signal integrity
• Single unit (EA) packaging for flexible deployment

Compatibility

Designed as an OEM-style patch cable for use with SC-port fiber patch panels, switches, transceivers, and media converters in OM3 multimode fiber infrastructures.

Installation Notes

Installation should be performed by a qualified low-voltage technician or structured cabling installer familiar with fiber optic handling procedures. De-energize connected equipment before connecting or disconnecting fiber patch cables to protect optical transceivers. Avoid exceeding the minimum bend radius of the cable during routing, and keep dust caps on unused ports and connectors until the moment of installation. Follow applicable local codes and TIA-568 structured cabling standards for fiber pathway and space requirements.
