Panduit F9TRP5NQSSNF018 OS2 12-fiber Mpo Harness

Product Description

The PANDUIT F9TRP5NQSSNF018 is an OS2 single-mode 12-fiber MPO harness cable rated for plenum (OFNP) installation environments. This fanout-style harness converts a single MPO connector on one end to individual fiber legs on the other, enabling structured cabling technicians and low-voltage installers to break out high-density trunk cables into discrete runs at distribution points. The OS2 single-mode designation makes it appropriate for long-distance, low-attenuation backbone and inter-building fiber links. The OFNP plenum rating allows installation in air-handling spaces without additional conduit protection where code permits.

This harness assembly is used in commercial and enterprise structured cabling projects where high-density MPO trunk systems are deployed in data centers, telecom rooms, and campus backbone pathways. It serves as the transition point between MPO trunk cables and individual LC, SC, or other simplex or duplex terminations at patch panels or active equipment. Installers working in plenum-rated ceiling spaces or air-handling ducts rely on the OFNP jacket to meet NFPA 90A and NEC Article 770 smoke and flame requirements.

Key Features

• OS2 single-mode fiber supports long-distance, low-loss backbone applications
• 12-fiber count in a single MPO interface reduces connector density at trunk connections
• OFNP plenum-rated jacket meets NEC Article 770 requirements for air-handling spaces
• MPO connector on the trunk end enables quick-connect compatibility with MPO patch panels and trunk systems
• Fanout harness construction simplifies termination to individual fiber ports at distribution points

Compatibility

Designed as an OEM-style harness for use with 12-fiber OS2 single-mode MPO trunk cabling systems in plenum-rated structured cabling installations.

Installation Notes

Installation should be performed by a qualified low-voltage or structured cabling technician familiar with fiber optic handling practices. Inspect all MPO connectors and fiber end-faces for contamination before mating, and clean with an appropriate fiber optic cleaning tool prior to connection. Observe minimum bend radius requirements throughout the cable route to prevent signal degradation. Reference NEC Article 770 and applicable local codes when routing OFNP cables in plenum or air-handling spaces.
