Panduit F92ERB1LNSNM030 OS2 Duplex Fiber Patch Cable

Product Description

The PANDUIT F92ERB1LNSNM030 is an OS2 singlemode duplex fiber optic patch cable designed for low-loss, high-bandwidth structured cabling installations. Built with a 1.6mm duplex jacket and LC/APC connectors on each end, this cable delivers precise angled physical contact terminations that reduce back-reflection in singlemode applications. At 3 meters in length, it is suited for short patch runs between equipment in data centers, telecom rooms, and network distribution frames. Network technicians and low-voltage installers use this cable in backbone and horizontal fiber infrastructure where signal integrity is critical.

This patch cable is used in OS2 singlemode fiber plants operating at 1310nm or 1550nm wavelengths. It is well suited for data center interconnects, server room patch panels, and enterprise network closets where duplex LC/APC connectivity is required. The OFNR (Optical Fiber Nonconductive Riser) rating qualifies it for installation in riser-rated cable pathways between floors in commercial buildings. It is appropriate for both new installations and moves, adds, and changes in existing fiber infrastructure.

Key Features

• OS2 singlemode fiber optimized for long-distance, low-attenuation signal transmission
• LC/APC connectors on both ends provide angled physical contact for reduced back-reflection
• 1.6mm duplex jacket construction for flexible routing in tight spaces
• OFNR riser rating meets NEC requirements for vertical riser cable pathways
• 3 meter length suits standard equipment-to-patch-panel runs in structured cabling environments

Compatibility

Designed for use in OS2 singlemode fiber optic cabling systems utilizing duplex LC/APC port interfaces on switches, transceivers, patch panels, and fiber distribution units.

Installation Notes

Installation should be performed by a qualified low-voltage technician or network cabling professional familiar with fiber optic handling practices. Avoid exceeding the minimum bend radius of the cable during routing to prevent signal degradation or fiber damage. Clean LC/APC connectors with an appropriate fiber optic cleaning tool before mating to ensure low insertion loss. Follow applicable NEC riser installation requirements when routing through vertical pathways.
