Panduit F92ELQ1Q1SNM045 OS2 Duplex Fiber Patch Cable

Product Description

The PANDUIT F92ELQ1Q1SNM045 is an OS2 singlemode duplex fiber optic patch cable designed for structured cabling installations in commercial and industrial environments. Built with a 1.6mm diameter cable jacket rated LSZH (Low Smoke Zero Halogen), it uses LC-style push-pull connectors on both ends for secure, tool-free engagement and clean, repeatable disconnects. This cable is suited for data center, enterprise LAN, and telecommunications backbone applications where low-attenuation singlemode transmission is required. Licensed network technicians and low-voltage cabling contractors are the typical installers.

This patch cable is used in OS2 singlemode fiber runs connecting patch panels, switches, transceivers, and active equipment in 9/125-micron optical infrastructure. The LSZH jacket makes it appropriate for use in plenum-adjacent or enclosed spaces where flame spread and toxic smoke emission must be minimized per building and fire codes. The push-pull LC connector format is well-suited for high-density panels where standard tab-style connectors are difficult to actuate by hand.

Key Features

• OS2 singlemode 9/125-micron fiber for low-loss long-distance transmission
• Duplex configuration with LC push-pull connectors on both ends
• 1.6mm LSZH cable jacket reduces smoke and halogen emissions in enclosed spaces
• Push-pull connector housing allows easy extraction in high-density patching environments
• Polished PC (Physical Contact) ferrules for low back-reflection at each mating interface

Compatibility

Designed as an OEM-style replacement or standard-issue patch cable for OS2 singlemode fiber infrastructure using LC-style duplex connector ports.

Installation Notes

Installation should be performed by a qualified low-voltage cabling technician or fiber optic installer following TIA-568 and applicable local codes. Inspect ferrule end-faces before mating and use appropriate fiber optic cleaning tools to remove contamination. Never bend the cable beyond its minimum bend radius and avoid placing tension on the connector boot during routing. Keep dust caps in place on unused connectors until the moment of insertion.
