Panduit F92ELQ1Q1SNM042 OS2 Duplex Fiber Patch Cable

Product Description

The PANDUIT F92ELQ1Q1SNM042 is an OS2 single-mode duplex fiber optic patch cable designed for structured cabling installations in commercial and enterprise network environments. Built with a 1.6mm cord diameter and Low Smoke Zero Halogen (LSZH) jacket material, this cable is suited for indoor deployments where fire and smoke safety ratings are required. The push-pull connector design allows technicians to seat and release the connector in high-density patch panels without the need for excessive reach or special tools. This cable carries two fibers in a duplex configuration and ships as a single assembly.

This patch cable is used in data centers, telecommunications rooms, and enterprise LAN backbone runs where OS2 single-mode performance is required. The LSZH jacket meets indoor plenum-adjacent safety standards and is commonly specified in schools, hospitals, and commercial buildings where halogen-free materials are required by code or facility policy. The push-pull form factor makes it well suited for high-density fiber panels where standard LC latch access is restricted. Installation is handled by low-voltage technicians, structured cabling installers, and network engineers.

Key Features

• OS2 single-mode fiber for long-distance, low-attenuation transmission
• Duplex configuration with 2 fibers in a single assembly
• 1.6mm cord diameter for flexible routing in tight cable management
• LSZH jacket reduces toxic smoke and halogen emissions in enclosed spaces
• Push-pull connector design enables tool-free extraction in high-density environments
• PC (Physical Contact) polish on fiber end faces minimizes back-reflection

Compatibility

Designed as an OEM-style replacement and standard fitment patch cable for OS2 single-mode fiber optic systems using push-pull LC-style connectors in structured cabling panels and active equipment.

Installation Notes

Installation is performed by licensed low-voltage technicians or structured cabling professionals in accordance with ANSI/TIA-568 standards. Inspect end faces with a fiber inspection scope before insertion to avoid contamination-related signal loss. Do not exceed the minimum bend radius of the cable during routing or dressing. Power down connected active equipment where fiber transceivers are involved before disconnecting patch cables to protect both equipment and eyes from laser exposure.
