Panduit F92ELQ1Q1SNM033 OS2 Fiber Patch Cord

Product Description

The PANDUIT F92ELQ1Q1SNM033 is an OS2 single-mode duplex fiber optic patch cord designed for structured cabling installations in commercial and industrial environments. Built with a 1.6mm low-smoke zero-halogen (LSZH) jacket, this patch cord supports high-bandwidth, long-distance optical transmission. The PushPull connector design allows for secure, tool-free mating and removal in high-density panels where access is limited. Licensed electricians and low-voltage cabling technicians are the primary installers of this assembly.

This patch cord is suited for data center, enterprise LAN, and telecom room applications where OS2 single-mode glass fiber is specified. The LSZH jacket makes it appropriate for plenum-adjacent or enclosed spaces where low smoke emission and halogen-free materials are required by fire or building codes. The duplex 2-fiber construction supports full-duplex transceiver links on switches, routers, media converters, and optical network equipment.

Key Features

• OS2 single-mode fiber for long-distance, high-bandwidth optical links
• Duplex 2-fiber construction supports full-duplex transmit and receive paths
• 1.6mm LSZH jacket rated for low smoke and zero halogen emission
• PushPull connector interface enables tool-free insertion and extraction in dense panels
• PC (physical contact) polish on ferrules reduces back-reflection at the connector interface

Compatibility

Designed as an OEM-style replacement and standard-fit patch cord for OS2 single-mode fiber optic panels, switches, and transceivers accepting the connector type specified in the part number configuration.

Installation Notes

Installation should be performed by a qualified low-voltage cabling technician or licensed electrician familiar with structured cabling standards such as ANSI/TIA-568. Before patching, inspect ferrule end-faces and clean with an approved fiber optic cleaning tool to prevent contamination-related loss. Do not exceed the minimum bend radius of the cable during routing. Avoid overtensioning or kinking the LSZH jacket, as physical damage to single-mode fiber is not always visually apparent.
