Panduit CTAPR2/0-2/0-X Copper Compression Connector

Product Description

The PANDUIT CTAPR2/0-2/0-X is a C-style copper compression connector designed for making reliable, low-resistance electrical splices in copper conductor applications. The compression-style design creates a permanent, gas-tight connection when installed with the appropriate compression tooling. This connector is suited for 2/0 AWG copper conductors and is typically installed by licensed electricians working on power distribution, grounding, or large-circuit wiring. The C-style body profile allows the conductor to be seated and compressed from the open side, making it a practical choice for field splicing and tap connections.

This connector fits 2/0 AWG copper conductors and is used in residential service entrances, commercial power distribution panels, and industrial wiring applications where a compact, durable splice is required. It is sold individually and is appropriate wherever code-compliant copper-to-copper compression connections are needed in conduit runs or enclosures.

Key Features

• C-style body profile for open-barrel conductor seating and compression splicing
• Rated for 2/0 AWG copper conductors
• Copper construction provides excellent conductivity and corrosion resistance
• Compression installation creates a permanent, gas-tight connection
• Sold individually for precise quantity purchasing

Compatibility

Designed as an OEM-style compression splice connector for use with 2/0 AWG copper conductors in standard electrical wiring and power distribution installations.

Installation Notes

Installation requires a licensed electrician using a compatible compression tool rated for the connector and conductor size. De-energize and lock out all circuits before beginning work, in accordance with NFPA 70 (NEC) and applicable OSHA lockout/tagout procedures. Ensure conductor ends are cut cleanly and stripped to the correct length before insertion. Do not use this connector with aluminum conductors unless explicitly rated for aluminum by the manufacturer.
