Panduit BS100845 Braided Bonding Strap

Product Description

The PANDUIT BS100845 is a braided bonding strap used to establish a reliable low-impedance electrical bond between conductive components. Bonding straps of this type carry fault current and equalize potential between grounded surfaces, reducing the risk of arcing, corrosion, and interference in electrical and grounding systems. The braided construction allows for flexible routing in tight or vibrating installations. This part is sold as a single unit and is typically installed by licensed electricians and grounding system technicians during panel, equipment, or structural bonding work.

Braided bonding straps are used in a wide range of applications including electrical panel grounding, equipment bonding, conduit system continuity, and structural steel bonding in both residential and commercial settings. They are suited for installations where a flexible, low-resistance connection is needed between two bonding points. The BS100845 is a single-unit item appropriate for service, retrofit, and new construction work.

Key Features

• Braided construction provides flexibility and accommodates vibration or movement between bonded surfaces
• Designed for low-impedance bonding connections in grounding system applications
• Single-unit packaging for precise quantity control in service and repair work
• One-hole termination end for straightforward lug or bus bar attachment

Compatibility

Designed as an OEM-style bonding solution for use in electrical grounding and bonding assemblies requiring a flexible braided strap with one-hole termination hardware.

Installation Notes

Installation should be performed by a licensed electrician in accordance with NEC bonding and grounding requirements. De-energize all affected circuits and verify the absence of voltage before making or breaking bonding connections. Ensure mating surfaces are clean and free of oxidation to achieve a proper low-resistance bond. Do not over-torque termination hardware beyond the fastener or lug manufacturer specifications.
