Panasonic S-800 Atmosphere Vortex Mixed Flow Fan 711 CFM

Product Description

The Panasonic S-800 Atmosphere Vortex Mixed Flow Fan is suitable for both residential and light commercial ventilation. The fan has an eight-inch duct diameter, making it appropriate for supply or exhaust ventilation systems.

• Compact design with efficient mixed flow impeller.
• Simple installation with included mounting brackets.
• Features a S-Line motor with thermal overload protection and automatic reset.

Product Highlights

This mixed flow fan allows for high airflow and operates quietly. Its internal impeller design enhances motor coolness, ensuring durability.

Product Information

Standard Information

• Brand: Panasonic
• Product Type: Exhaust Fan

Technical Specifications

• Model: S-800
• Duct Diameter: 8 inches
• Airflow: 711 CFM
• Sones: 1
• Length: 10 inches
• Width: 14 inches
• Depth: 14 inches
• Amperage: 1.99A
• Voltage: 120V
• Wattage: 232W
• Drive Type: Direct Drive
• Power Source: Plug-In
• Speeds: 1
• Certifications: ETL
• Approved for Commercial Use: Yes
• Warranty: 10-year
• Motor Type: 100% speed controllable
• Bearings: Permanently lubricated ball bearings
• Protection: Thermal overload with automatic reset
• Installation: Mounting brackets included
