PANASONIC S-600 Atmosphere Vortex Mixed Flow Fan 340 CFM

Product Description

The PANASONIC S-600 Mixed Flow Fan is suitable for residential and light commercial ventilation tasks. This fan features a mixed flow impeller for effective airflow with quiet performance. The motor is fully controllable and has thermal overload protection with an automatic reset function.

• Quiet operation with a compact design
• Includes brackets for simple installation
• Designed for six-inch ducts

Product Highlights

This fan works well for both supply and exhaust ventilation systems. Its simple clipping system allows for easy removal and maintenance.

Product Information

Standard Information

• Brand: PANASONIC
• Model: S-600

Technical Specifications

• Duct Diameter: 6 inches
• Airflow: 340 CFM
• Sones: 1
• Length: 8.375 inches
• Width: 12.5 inches
• Depth: 12.5 inches
• Amperage: 0.68 A
• Voltage: 120 V
• Wattage: 72 W
• Fan Type: In-Line Fan
• Drive Type: Direct Drive
• Power Source: Plug-In
• Speeds: 1
• Approved for Commercial Use: Yes
• Certifications: ETL
• Collection: S-Line
• Warranty: 10 years
• Motor Type: 100% speed controllable
• Bearings: Permanently lubricated ball bearings
• Protection: Thermal overload with automatic reset
• Installation: Mounting brackets included
