Panasonic FV-06VE1 Whisper Comfort Energy Recovery Ventilator 20/30/40/50/Boost 60 CFM

Product Description

The Panasonic FV-06VE1 Whisper Comfort Energy Recovery Ventilator provides a tempered fresh air supply and balanced exhaust air flow to maintain neutral pressure throughout the home. It features a high-efficiency capillary core that recovers heat and maintains moisture levels. The multi-speed selector provides customizable airflow from 20 to 50 CFM, with a boost function up to 60 CFM. Mountable on ceilings or walls for seamless integration.

• Provides tempered fresh air and balanced exhaust.
• Features a multi-speed selector for customizable airflow.
• Easy to install on ceilings or walls.

Product Highlights

This energy recovery ventilator is HVI certified for energy recovery and sound, with static pressure access ports for easy airflow verification.

Product Information

Standard Information

• Brand: PANASONIC
• Manufacturer Part Number: FV-06VE1
• Country of Origin: Mexico

Technical Specifications

• Brand: Panasonic
• Max Airflow (CFM): 60
• Motor: Condenser
• Blower Wheel Type: Sirocco
• Motor Bearing: Ball
• Mount: Ceiling Recessed, Wall
• Mounting Opening: 10-1/4"
• Grille Size: 13"
• Material: Galvanized Steel
• Duct Size: 4 in
• Voltage: 120v
• Hertz: 60
• Features: Energy Star Qualified
• Thermal Fuse Protection: Yes
• Warranty: 3 Year (Parts)
• Model: FV-06VE1
• Voltage Rating: 120 V
• Frequency Rating: 60 Hz
• Power Rating: 39 W, 12 W
• Pressure Rating: 0.25 in-WG
• Finish: Galvanized
• Mounting Type: Ceiling, Wall
• Temperature Rating: 32 deg F, 95 deg F
• Length: 23-5/8 in
• Width: 15-3/4 in
• Height: 8-7/8 in
• Domestic/Import: Import
• Wattage: 50 watts
• Air Flow Capacity: 60 Cubic Feet Per Minute
• Indoor/Outdoor Usage: Indoor
• Efficiency: High efficiency
• Installation Type: Ceiling/Wall Mount
