Packard TSMJ270 Motor Start Capacitor 165 VAC (Size 4)

Product Description

Packard TSMJ270 is a motor start capacitor rated 270–324 MFD for 165 VAC service, intended for intermittent duty in AC motor starting circuits. It is a dry, electrolytic, non-polarized capacitor in a moisture- and oil-resistant molded phenolic resin or plastic round case (can/case size 4) with standard dual blade terminals. Rated for 3-second starts, up to 20 starts per hour, and suitable for 50/60 Hz applications with operating range -40 to 65°C.

• Capacitance 270–324 MFD, rated voltage 165 VAC, suitable for 50/60 Hz motor starting.
• Dry electrolytic, non-polarized construction with moisture- and oil-resistant molded phenolic/plastic case; can/case size 4; dimensions 1.8125 in diameter × 3.50 in height.
• Standard dual blade terminals; rated 3-second start duty with up to 20 starts per hour; operating temperature -40 to 65°C (-40 to 149°F).

Product Highlights

270–324 MFD motor start capacitor for 165 VAC motors, size 4 case, 3-second start duty, suitable for 50/60 Hz applications.

Product Information

Standard Information

• Brand: PACKARD
• Manufacturer Part Number: TSMJ270
• Country of Origin: United States

Technical Specifications

• Brand: Packard
• MPN: TSMJ270
• Type: Motor start capacitor
• Capacitance (Start MFD): 270-324
• Rated Voltage: 165 VAC
• Frequency: 50/60 Hz
• Can/Case Size: 4
• Diameter (in): 1.8125
• Height (in): 3.50
• Material: Moisture- and oil-resistant molded phenolic resin or plastic
• Terminals: Standard dual blade terminals
• Construction: Dry electrolytic, non-polarized
• Duty: Intermittent motor starting
• Rated Start: 3-second start
• Starts Per Hour: Up to 20
• Operating Temperature: -40 to 65°C (-40 to 149°F)
• EIA Standard: Meets or exceeds EIA RS-463 type 2
• Condition: New
• Country of Origin: United States
• UPC: 0840899130408
