Packard BC378-165 Cap Psmj378 16378

Product Description

The PACKARD BC378-165 Cap Psmj378 16378 is designed for intermittent Standard AC duty. These capacitors are used in starting fractional horsepower, single-phase electric motors, as well as in gear motor applications. The capacitors are housed in rugged plastic cases, which require no added insulation and are moisture and oil resistant.

• Individually boxed and made in the USA.
• Features 1/4" Quick Disconnect Terminals (Standard).
• UL 810 Recognized & Approved and operates at 50 / 60 Hz frequency with -40 to +65°C operating temperature.

Product Highlights

This capacitor replaces Aerovox 092A378B125AD2A, MARS 11023, JARD 11923, Global 1023, Packard PMJ378, Vanguard BC-378 CS378-440x110 and other Start Capacitors with this uF/Mfd & VAC Rating.

Product Information

Standard Information

• Brand: PACKARD
• Manufacturer Part Number: BC378-165
• Country of Origin: USA

Technical Specifications

• Capacitance: 378 Microfarad
• Brand: Packard
• Material: Aluminum, Plastic
• Shape: Round
• Operating Voltage: 125 Volts
• Maximum Voltage: 125 Volts
• Mounting Type: Snap-In Mount
• Upper Temperature Rating: 65 Degrees Celsius
• Manufacturer: BMI
