Osg 800-8018 Carbide Bur Ball SD-41 3/32 in Double Cut

Product Description

The OSG 800-8018 is a double-cut carbide abrasive bur with a ball head shape, designed for aggressive material removal on hard and tough workpieces. It features a 3/32-inch cutting diameter and mounts on a 1/8-inch shank, with an overall length of 1.5 inches. The uncoated carbide head delivers durability and edge retention across a wide range of demanding materials. This bur is used by machinists, tool and die makers, welders, and fabricators for deburring, grinding, shaping, and surface blending in both production and maintenance applications.

The 800-8018 is suited for use on steel, stainless steel, cast iron, superalloys, and titanium, as well as other hard materials. The ball profile makes it well suited for contoured surfaces, concave profiles, and cavity work where a flat or cylindrical bur would lose contact. It is rated for use at up to 85,000 RPM, making it compatible with high-speed die grinders and rotary tools commonly found in machine shops, fabrication facilities, and MRO environments.

Key Features

• Ball head shape for contoured surface and cavity grinding
• Double-cut tooth style for fast stock removal and smooth finish
• Carbide head construction handles steel, stainless steel, cast iron, superalloys, and titanium
• 85,000 RPM maximum speed rating suits high-speed die grinders
• 3/32-inch cutting diameter on a 1/8-inch shank fits standard collets
• Uncoated finish — no coating delamination risk at high RPM

Compatibility

Meets industry specification SD-41. Designed for use with standard 1/8-inch collet die grinders and rotary tools used in machining, fabrication, and MRO applications on steel, stainless steel, cast iron, superalloys, titanium, and other hard materials.

Installation Notes

Install the shank fully and securely into the collet of a die grinder or rotary tool before operation. Verify the tool's rated RPM meets or exceeds the workpiece requirements but does not exceed the 85,000 RPM maximum rating of this bur. Wear appropriate eye protection and secure the workpiece before contact. Inspect the bur for cracks or chip damage before each use and remove from service if any defects are found.
