Osg 5460400 Square End Mill 5/16 Inch 4 Flute Cobalt

Product Description

The OSG 5460400 is a cobalt square end mill designed for material removal in metalworking and machining operations. Built from M42 cobalt high-speed steel, it provides greater heat and wear resistance than standard HSS tooling, making it well suited for harder steels, stainless, and abrasive alloys. The 5/16 inch cutting diameter pairs with a 3/8 inch shank, a 1-3/8 inch length of cut, and a 3-1/8 inch overall length. The 30-degree spiral helix and 4-flute geometry promote chip evacuation and deliver a fine surface finish on finish passes. This is a center-cutting tool, allowing direct plunge entry without a pre-drilled hole.

This end mill fits standard milling applications in job shops, toolrooms, and production environments. It is sized for use in manual knee mills, CNC machining centers, and drill press setups where a 3/8 inch collet or end mill holder is available. The long-length geometry provides additional reach for deeper pockets or stepped workpieces. Right-hand cut and right-hand flute configuration matches conventional spindle rotation on standard machines. Series 546 identifies this as part of OSG standard cobalt long-length tooling line.

Key Features

• M42 cobalt construction for improved heat resistance over standard HSS
• 4 flutes with 30-degree helix for efficient chip evacuation and surface finish
• Center-cutting design allows direct plunge milling without a pilot hole
• Right-hand cut and right-hand flute for use with standard machine spindle rotation
• Long-length geometry with 1-3/8 inch LOC for deeper pocket reach
• Uncoated finish suitable for use with cutting fluid on ferrous and non-ferrous materials

Compatibility

Designed for use in any milling machine or machining center equipped with a 3/8 inch collet, end mill holder, or similar toolholding system. Fits OSG Series 546 long-length cobalt end mill applications.

Installation Notes

Installation should be performed by a qualified machinist or toolroom technician. Ensure the machine spindle is fully stopped and locked out before changing tooling. Seat the shank to the full recommended engagement depth in the collet or holder to prevent pullout under cutting loads. Do not exceed the tool manufacturers recommended speeds and feeds for the workpiece material and depth of cut.
