OSG 2806401 #4-40 HY-PRO Spiral Point Plug Tap, HSSE, 2-Flute, H2, Steam Oxide Finish

Product Description

The OSG 2806401 #4-40 HY-PRO Spiral Point Plug Tap is designed to cut screw threads inside holes. It is made from high speed steel to ensure durability and precision. This tap is ideal for a variety of applications in different industries.

• Made from high speed steel for increased durability
• Spiral point design for efficient chip removal
• Steam oxide finish for enhanced lubricity

Product Highlights

The tap is part of the HY-PRO series, well-regarded in the industry for high performance and reliability.

Product Information

Standard Information

• Brand: OSG
• Country of Origin: BR

Technical Specifications

• Series: HY-PRO 280
• Material: HSS-E
• Thread Size: #4-40
• Chamfer Type: 3.5P-4.5P Plug
• Thread Limit: H2
• Thread Length: 0.295 inches
• Finish/Coating: Steam Oxide
• Overall Length: 1.87 inches
• Shank Diameter: 0.14 inches
• Thread Standard: UNC
• Number of Flutes: 2
• Cutting Direction: Right Hand
• Measurement System: Imperial
• Material Application: Steel, Stainless Steel, Tool Steel, Die Steel and Nickel Alloys
• Through Coolant: No
