Oatey 5340h Heavy Floor Ceiling Plate Chrome 1/2 in

Product Description

The OATEY 5340h is a heavy-duty steel floor and ceiling plate finished in chrome, designed to cover pipe penetrations through floors, ceilings, and walls in residential and light commercial plumbing installations. Built for 1/2 inch pipe diameter, it features a 5/8 inch inside diameter and a 2-13/16 inch outside diameter, giving it a clean, finished appearance around exposed pipe runs. The chrome finish resists tarnish and blends with standard trim hardware. Plumbers and finish contractors install these plates as a final trim step to conceal rough openings and provide a professional appearance at pipe entry and exit points.

This plate is suited for use with 3/4 inch tube and fits standard 1/2 inch pipe. Typical applications include supply line stub-outs at sinks, toilets, and appliances, as well as drain and vent pipe penetrations through framing members. The heavy designation indicates a thicker, more substantial plate compared to standard escutcheons, making it appropriate for higher-traffic or more visible installations where a lighter plate would look undersized or flex under contact.

Key Features

• Heavy steel construction for a solid, durable feel at pipe penetrations
• Chrome finish provides a clean, corrosion-resistant appearance
• 1/2 inch pipe diameter fitment with 5/8 inch inside diameter opening
• 2-13/16 inch outside diameter covers standard rough-in openings
• Compatible with 3/4 inch tube applications
• Suitable for floor, ceiling, and wall installations

Compatibility

Designed for use with 1/2 inch pipe and 3/4 inch tube in standard residential and light commercial plumbing trim-out applications.

Installation Notes

Installation is performed by licensed plumbers or finish trim contractors during the final stage of a plumbing rough-in or remodel. Shut off the water supply before any nearby pipe work is performed. Slide the plate over the pipe before making final connections, as it cannot be installed after fittings are in place. No special tools are required; the plate rests flush against the floor or ceiling surface around the pipe.

Technical Specifications

• Material: Steel
• Finish: Chrome
• Type: Heavy
• Pipe Diameter: 1/2 inch
• Inside Diameter: 5/8 inch
• Outside Diameter: 2-13/16 inches
• For Use With: 3/4 inch tube

Standard Information

• Brand: OATEY
• Manufacturer Part Number: 5340h
