Oatey 45314 1SVR405613R1100 ABB Pluggable Interface RelayCR-M024DC4L

Product Description

Oatey, 45314, is a pluggable miniature relay designed for various industrial applications. This relay operates with a control supply voltage of twenty-four VDC. The relay has a four C/O (SPDT) output with a maximum contact rating of six A at two hundred fifty V. It features socket mounting, an integrated LED display, and operates within a temperature range from negative forty to seventy degrees Celsius. The dimensions are twenty-one point two mm in width, twenty-seven point five mm in depth, and thirty-five point six mm in height.

• General purpose relay with integrated test button
• LED indication for operational status
• Suitable for standard and logical sockets

Product Highlights

This relay features a reverse polarity prediction and free wheeling diode for better performance and safety in electrical circuits.

Product Information

Standard Information

• Manufacturer: Oatey
• UPC: 03262845314

Technical Specifications

• Amperage Rating: 6 A
• Coil Voltage: 24 VDC
• Contact Form: 4CO-SPDT
• Contact Rating: 6 A at 250 V
• Dimensions: 21.2 mm W x 27.5 mm D x 35.6 mm H
• Enclosure: IP40
• Manufacturer Part Number: 1SVR405613R1100
• Mounting Type: Socket
• Power Rating: 1500 W
• Series: CR-M
• Standards/Approvals: CE Certified|CCC Certified|cUR Listed|CSA Certified|EAC Certified|GOST Certified|LR Certified|RMRS Certified|RoHS Compliant|VDE Certified|UR Listed
• Temperature Rating: -40 to 70 deg C
• Type: Pluggable Miniature
