Nvent CSP2420 Swing-out Panel

Product Description

The NVENT CSP2420 is a swing-out panel designed for use inside electrical enclosures. It provides a mountable interior surface that pivots outward, giving technicians clear access to wiring, terminal blocks, DIN rails, and control components without removing the enclosure door. This type of panel is commonly installed by licensed electricians and control panel builders working on industrial, commercial, or utility electrical systems. At 17.8 pounds, the CSP2420 offers a solid, sturdy platform suited for organized component layout and serviceability.

Swing-out panels like the CSP2420 are used in applications where frequent access to control wiring or field devices is required. Typical installations include motor control centers, process control enclosures, HVAC control panels, and general-purpose electrical distribution enclosures. The swing-out design reduces service time by eliminating the need to work in a confined fixed-panel space. This panel is intended for professional installation inside a compatible enclosure cabinet.

Key Features

• Swing-out design allows full panel access without removing enclosure door
• Sturdy construction at 17.8 pounds supports terminal blocks, DIN rails, and control devices
• Designed for organized interior component layout in control enclosures
• Reduces service time during maintenance or troubleshooting

Compatibility

Designed as an OEM-style swing-out panel for use inside compatible electrical enclosures requiring interior panel mounting.

Installation Notes

Installation should be performed by a qualified electrician in accordance with applicable NEC requirements. De-energize all circuits and lock out the enclosure before beginning panel installation or modification. Verify that the panel dimensions are compatible with the target enclosure interior before mounting. Secure all hardware to manufacturer torque guidelines as specified in the enclosure documentation.

Technical Specifications

• Weight: 17.8 pounds
• UPC: 78351012370

Standard Information

• Brand: NVENT
• Manufacturer Part Number: CSP2420
