Nvent ASE10X8X4NK Pull Box 10 x 8 x 4 in (Replacement ASE10X8X4NK)

Product Description

Nvent ASE10X8X4NK is a steel pull/junction box (Series A90P1) measuring 10 in x 8 in x 4 in with a screw cover and NEMA 1/IP30 protection. The enclosure has a polyester powder-painted finish, flat removable cover fastened with plated steel screws, provision for grounding, and mounting holes on the back. It is intended for commercial and general industrial junction and pull-box applications.

• Steel construction, Series A90P1, dimensions 10 in (H) x 8 in (W) x 4 in (D); NEMA 1 / IP30 rated
• Screw cover with flat removable panel fastened by plated steel screws; provision for grounding and rear mounting holes
• Polyester powder-painted finish; supplied without knockouts; optional flush covers and door frames available separately

Product Highlights

Steel NEMA 1/IP30 pull/junction box, 10 x 8 x 4 in, screw cover, no knockouts, flush-mount ready

Product Information

Standard Information

• Brand: NVENT
• Manufacturer Part Number: ASE10X8X4NK

Technical Specifications

• Brand: Nvent
• Manufacturer Part Number: ASE10X8X4NK
• Series: A90P1
• Enclosure Type: Pull / Junction Box
• Material: Steel (mild steel)
• Finish: Polyester powder painted (ANSI 61)
• Mounting Type: Flush
• Cover Type: Screw cover, flat removable
• NEMA Rating: NEMA 1
• IP Rating: IP30
• Dimensions (Height x Width x Depth): 10 in x 8 in x 4 in
• Height: 10 in (254 mm)
• Width: 8 in (203 mm)
• Depth: 4 in (102 mm)
• Body Thickness: 16 ga (approx. 1.52 mm)
• Door Thickness: 16 ga
• Knockouts Included: No
• Cover Screw Quantity: 4
• Weight: 5.4 lb
• Application: Commercial and general industrial junction or pull box
• Standards/Approvals: UL 50/50E Listed File No. E27525; cUL Listed per CSA C22.2 No. 40 File No. E27525; IEC 60529 IP30; NEMA/EEMAC Type 1
• Bulletin Number: A90P1
