Numatics INB103-104-020 Pneumatic Connector 1/4 x 1/8 in TubexMNPT

Product Description

Numatics Pneumatic Connector, MPN INB103-104-020, is designed for reliable connections in pneumatic systems. This connector features a nominal size of one-fourth by one-eighth inches, allowing it to connect tubes with male NPT threads efficiently. It is suitable for a wide range of applications within different piping systems.

• Push-in fittings with NPTF threads
• Temperature range of minus twenty to one hundred seventy-six degrees Fahrenheit
• Maximum pressure rating of two hundred sixty-five psi

Product Highlights

This connector is designed for ease of installation and strong performance under varying conditions.

Product Information

Standard Information

• Brand: Numatics
• Manufacturer: Emerson Electric

Technical Specifications

• Dimensions: 0.5 in W x 0.551 in H
• Domestic/Import: Domestic
• End Style: Tube x MNPT
• Finish: Nickel Plated
• Fitting/Connector Type: Connector
• Hex Size: 1/2 in
• Material: Brass
• Nominal Size: 1/4 x 1/8 in
• Pressure Rating: 265 psi
• Series: INB
• Temperature Rating: -20 to 176 deg F
