Norton 66252843596 Type 27 Grinding Wheel 5 in 24 Grit

Product Description

The NORTON 66252843596 is a Type 27 depressed center grinding wheel designed for aggressive material removal on metal surfaces. Built with aluminum oxide abrasive bonded in a resinoid bond matrix, this wheel delivers coarse 24-grit cutting action suited for weld grinding, surface prep, and deburring tasks. The depressed center profile allows flat-to-surface grinding without the hub interfering with the workpiece. Rated to a maximum of 12,225 RPM, the wheel measures 5 inches in diameter and 1/8 inch thick with a 7/8-inch arbor hole. At 0.12 pounds, it is a lightweight consumable used by metalworkers, fabricators, and maintenance trades.

This wheel fits standard 5-inch angle grinders commonly used in fabrication shops, maintenance facilities, and construction sites. It is suited for grinding mild steel, cast iron, and similar ferrous metals. The 7/8-inch arbor hole is the standard size for most 5-inch right-angle grinders, making this a drop-in fit for common portable tools. The coarse 24-grit rating makes it best suited for stock removal rather than finishing work.

Key Features

• Type 27 depressed center profile for flat-surface grinding clearance
• Aluminum oxide abrasive with resinoid bond for durability under load
• 24-grit coarse grade for aggressive stock removal and weld grinding
• 12,225 maximum RPM rating for use with standard 5-inch angle grinders
• 7/8-inch arbor hole fits most common portable grinder spindles
• Lightweight at 0.12 pounds for reduced operator fatigue during extended use

Compatibility

Designed for use with 5-inch angle grinders equipped with a 7/8-inch arbor. Suitable for grinding ferrous metals including mild steel and cast iron in fabrication and maintenance applications.

Installation Notes

Mounting and wheel changes must be performed by qualified personnel following ANSI B7.1 safe practices for abrasive wheel use. Always power down and disconnect the grinder from its power source before mounting or removing the wheel. Inspect the wheel for cracks or damage before each use and never exceed the rated maximum RPM marked on the wheel. Wear appropriate eye protection and a face shield during operation.
