Norton 66252838322 Type 2 Grinding Wheel 6 in 60 Grit

Product Description

The NORTON 66252838322 is a Type 2 vitrified silicon carbide grinding wheel designed for tool grinding and cutting applications. At 6 inches in diameter and 1 inch face width, it runs at a maximum of 3,600 RPM and carries a 60-grit, medium-grade (Hardness Code I) specification. The vitrified bond provides rigidity and consistent stock removal on ferrous and non-ferrous materials. This wheel is sold individually and is used by machinists, tool-and-die specialists, and maintenance technicians who need a reliable bench or pedestal grinder wheel for sharpening carbide-tipped tooling and similar applications.

This wheel suits bench and pedestal grinder setups in machine shops, maintenance facilities, and industrial service environments. The green silicon carbide composition makes it appropriate for grinding hard, brittle materials such as tungsten carbide, ceramics, and cast iron. It fits arbors with a 1-1/4-inch hole, which is a standard size on many bench grinders used in trade and industrial settings. Licensed machinists and maintenance professionals typically select this wheel for precision tool reconditioning work.

Key Features

• Silicon carbide abrasive material for hard, brittle workpiece materials
• Vitrified bond provides rigidity and consistent cut rate
• 60 grit, medium grade for balanced stock removal and surface finish
• Non-porous construction for stable, controlled grinding action
• Green wheel color aids visual identification as a silicon carbide grade
• Rated to 3,600 RPM maximum for safe bench and pedestal grinder use

Compatibility

Designed for bench and pedestal grinders accepting a Type 2 wheel with a 1-1/4-inch arbor hole and a 6-inch diameter.

Installation Notes

Grinding wheel installation and dressing must be performed by a qualified technician following ANSI B11.9 and applicable OSHA standards for abrasive wheel machinery. Always power down and lock out the grinder before mounting or changing wheels. Inspect the wheel for cracks or chips before installation and perform a ring test; do not mount a damaged wheel. Use flanges and blotters appropriate for a Type 2 wheel and never exceed the rated maximum RPM of 3,600.
