Norgren TF-5/16-1 1/8X2 Air Cylinder 1-1/8 in Bore

Product Description

The NORGREN TF-5/16-1 1/8X2 is a single acting rodless air cylinder engineered for pneumatic linear motion applications in industrial and mechanical systems. With a 1.125-inch bore and a 2-inch stroke, it delivers controlled, repeatable actuation at operating pressures up to 150 psi. The cylinder features a flush mount style and a 1/8 NPTF port for straightforward integration into existing pneumatic circuits. The 5/16-18 rod thread accommodates standard hardware. Licensed pneumatic system technicians and industrial mechanics are the typical installers for this component type.

This cylinder is suited for compact automation tasks where space constraints favor a flush mount configuration. It fits single acting pneumatic circuits in light to medium industrial machinery, assembly equipment, and process control systems. The 2-inch stroke makes it appropriate for short-travel actuation tasks such as clamping, indexing, or positioning. The operating temperature range of -20 to 200 degrees F allows use in a variety of ambient and process environments.

Key Features

• Single acting design for simplified pneumatic circuit integration
• 1.125-inch bore with 2-inch stroke for compact linear actuation
• 150 psi maximum working pressure
• 1/8 NPTF port for leak-resistant pneumatic connections
• Flush mount style for low-profile installation
• 5/16-18 rod thread for compatibility with standard fasteners
• Rated for -20 to 200 degrees F operating temperature range

Compatibility

Designed as an OEM-style single acting rodless air cylinder with flush mount configuration suitable for standard 1/8 NPTF pneumatic circuit installations.

Installation Notes

Installation should be performed by a qualified industrial mechanic or pneumatic systems technician. Depressurize and isolate the pneumatic supply line completely before removing or installing any cylinder components. Verify port thread compatibility with existing fittings before assembly to avoid cross-threading the NPTF port. Confirm that system supply pressure does not exceed the 150 psi rated maximum.
