Norgren RP031X1.000-DAD Rodless Air Cylinder 5/16 Bore

Product Description

The NORGREN RP031X1.000-DAD is a double acting rodless air cylinder designed for compact linear motion applications in pneumatic systems. With a 5/16 inch (0.31 inch decimal) bore and a 1 inch stroke, this cylinder delivers controlled bidirectional actuation using shop air or compressed air supply. A stainless steel body provides corrosion resistance for demanding environments. Maximum working pressure is rated at 250 psi (17.2 bar). The double end mount configuration allows secure, stable fixture to machine frames, brackets, or tooling plates. This cylinder is installed by mechanical and automation technicians working on pneumatic motion control assemblies.

This cylinder suits tight-clearance installations where a traditional rod-style cylinder would exceed available travel space. The 10-32 UNF port accommodates standard push-to-connect or barbed pneumatic fittings used in small-bore pneumatic circuits. The 3/8-24 mount thread and double end mounting style allow it to be integrated into precision fixtures, pick-and-place tooling, and light-duty actuator assemblies in industrial, HVAC control, or automated equipment applications. The 5-40 rod thread size enables direct attachment of end tooling or load hardware.

Key Features

• Double acting design provides powered extension and retraction for positive control in both directions
• Stainless steel body resists corrosion in wash-down or moisture-prone environments
• 5/16 inch bore with 1 inch stroke suits compact, low-force linear motion tasks
• 10-32 UNF port size is compatible with common small-bore pneumatic fittings
• Double end mount with 3/8-24 mount thread for rigid, stable installation
• 250 psi maximum working pressure supports standard plant air supply systems

Compatibility

Designed as an OEM-style replacement or direct-fit component for small-bore pneumatic actuator assemblies requiring a double acting rodless cylinder with a 5/16 inch bore, 1 inch stroke, and 10-32 UNF porting.

Installation Notes

Installation should be performed by a qualified pneumatic or mechanical technician. Depressurize and lock out the air supply before removing or installing any cylinder in a pneumatic circuit. Ensure all fittings are rated for the system working pressure and that port threads are not cross-threaded during fitting installation. Verify mount thread engagement and double end bracket alignment before returning the system to service.
