Norgren DC/92025/M/.25 Rodless Air Cylinder 1in Bore

Product Description

The NORGREN DC/92025/M/.25 is a double acting rodless pneumatic air cylinder built with a stainless steel body. It features a 1 inch bore and a 0.25 inch stroke, rated for a maximum working pressure of 145 psi. This cylinder converts compressed air pressure into linear motion without an extending rod, keeping the overall installed length compact. It is suited for automated equipment, tooling fixtures, and light industrial motion control applications. Installation and integration are typically handled by pneumatic system technicians or mechanical maintenance professionals familiar with compressed air systems.

This cylinder is designed for use in pneumatic automation setups where a short, precise stroke is required in a confined space. The rodless design allows the load to be mounted directly to the carriage, making it a practical choice for sliding actuator assemblies, guided linear motion stages, and OEM equipment builds. The 10-32 UNF port accommodates standard push-to-connect or threaded pneumatic fittings commonly found in small-bore pneumatic circuits.

Key Features

• Double acting design uses air pressure for both extension and retraction strokes
• Rodless construction reduces overall cylinder length for compact installations
• Stainless steel body provides corrosion resistance in demanding environments
• 145 psi maximum working pressure supports standard shop-air and regulated supply lines
• 10-32 UNF port size is compatible with widely available small-bore pneumatic fittings
• Square style body simplifies mounting to flat surfaces and fixture plates

Compatibility

Designed as an OEM-style replacement or direct-fit pneumatic actuator for small-bore rodless cylinder applications requiring a 1 inch bore, 0.25 inch stroke, and 10-32 UNF port connections.

Installation Notes

Installation is typically performed by a qualified pneumatic technician or industrial maintenance mechanic. Depressurize and lock out the compressed air supply before removing or installing any cylinder in the circuit. Verify port thread engagement and use appropriate thread sealant rated for pneumatic service. Confirm that supply pressure does not exceed 145 psi at the cylinder inlet.
