Norgren C00600400 Union Tee Fitting 4mm Brass 150 Psi

Product Description

The NORGREN C00600400 is a push-to-connect union tee tube fitting designed for tube-to-tube connections in pneumatic and fluid distribution systems. Constructed from brass, this fitting accepts 4mm outside diameter tubing and handles a maximum working pressure of 150 psi. The push-to-connect design allows for fast, tool-free tube insertion, reducing assembly time on the bench or in the field. An integrated nitrile O-ring provides a reliable seal across a working temperature range of 0 degrees F to 175 degrees F. This fitting is typically installed by HVAC technicians, pneumatic system integrators, and plumbing professionals working with small-bore tubing runs.

The C00600400 union tee is suited for residential and light commercial pneumatic control lines, instrumentation tubing, and low-pressure fluid distribution applications where a three-way branch connection is needed. The tee configuration allows a single inlet line to split into two outlets, or three lines to converge, without soldering, threading, or compression ferrules. Its compact overall length of 36.60mm makes it appropriate for tight panel or cabinet installations where space is limited.

Key Features

• Push-to-connect design for fast, tool-free tube insertion and release
• Brass construction for corrosion resistance in pneumatic and fluid service
• Accepts 4mm outside diameter tubing on all three ports
• Rated to 150 psi maximum working pressure
• Nitrile O-ring seal rated from 0 degrees F to 175 degrees F
• Compact form factor at 36.60mm overall length

Compatibility

Designed as an OEM-style push-to-connect union tee for pneumatic and fluid systems using 4mm outside diameter tubing.

Installation Notes

Installation of this fitting should be performed by a qualified technician familiar with pneumatic or fluid distribution systems. Before installing or removing the fitting, depressurize and isolate the line completely. To insert tubing, push the tube end firmly and squarely into the fitting port until it seats fully against the internal collet. To release, press the collet ring inward while pulling the tube free.
