Nomaco HDPEPIPE1-100 Hdpe Water Pipe 1 Inch 100 Feet

Product Description

The NOMACO HDPEPIPE1-100 is a 1-inch diameter high-density polyethylene (HDPE) water pipe supplied in a 100-foot coil. Manufactured to PE3408 material specification, this pipe is suited for potable water distribution, irrigation, and general water service applications. HDPE pipe offers excellent resistance to corrosion, scaling, and chemical degradation compared to metal pipe, making it a reliable long-term solution for underground and above-ground water conveyance. Licensed plumbers and irrigation contractors are the primary installers of this product.

This pipe is commonly used in residential and light commercial water service lines, rural water distribution, drip and sprinkler irrigation systems, and geothermal loop field piping. The 100-foot coil format is well suited for direct-bury runs from a meter pit or well head to a structure. PE3408-grade HDPE is widely accepted by municipal water authorities for potable water service connections.

Key Features

• PE3408 HDPE material grade for potable water service
• 1-inch nominal diameter in a 100-foot coil for continuous runs with fewer joints
• Corrosion-resistant and scale-resistant — no cathodic protection required
• Flexible construction allows coiled installation and routing around obstacles
• Suitable for direct-bury underground water service applications

Compatibility

Designed as an OEM-style replacement and standard-fit supply pipe for residential and light commercial water service, irrigation, and geothermal loop applications requiring 1-inch HDPE PE3408 pipe.

Installation Notes

Installation of HDPE water pipe should be performed by a licensed plumber or irrigation contractor in accordance with local plumbing codes and ASTM D2239 or D2737 standards as applicable. Shut off the water supply and depressurize the line before making any connections. Use fittings and clamps rated for HDPE pipe at the operating pressure of the system. Thermal fusion, insert fittings, or compression fittings compatible with HDPE are the accepted joining methods — do not use fittings rated for PVC or other incompatible pipe materials.

Technical Specifications

• Material: HDPE PE3408
• Nominal Pipe Diameter: 1 inch
• Length: 100 feet

Standard Information

• Brand: NOMACO
• Manufacturer Part Number: HDPEPIPE1-100
