NIBCO XNL114-3220 2 X 1-1/4 Brass Hex Bushing

Product Description

The NIBCO XNL114-3220 is a brass hex head pipe bushing created for plumbing uses. This is a reducing bushing with a two-inch MNPT (Male National Pipe Thread) end and a one and one-fourth inch FNPT (Female National Pipe Thread) end. Made from brass, this fitting offers durability and resistance to corrosion. The softer nature of brass aids in achieving a tight seal and promotes easy installation.

• Fitting Type: Bushing, Hex Head, Reducing
• End Connections: MNPT x FNPT
• Material: Brass

Product Highlights

This bushing is suitable for a variety of settings including commercial, plumbing, OEM, water, oil, gas, and steam applications.

Product Information

Standard Information

• Size 1: 2 inches
• Size 2: 1-1/4 inches

Technical Specifications

• Pressure Class: 125 lb
• Maximum Pressure: 200 psi
• Temperature Range: -20 to 400 degrees F
• Material Specification: ASTM 584-06A
• Applicable Standard: ANSI/ASME B16.14/B15.15/B16.18/B1.20.1
• End Style: MNPT x FNPT
