Nibco PC201 1-1/4 Press x Press Coupling (1-1/4) 2020550EPC

Product Description

The NIBCO PC201 1-1/4 is a BenchPress carbon steel press x press coupling designed to join or repair 1-1/4-inch black iron pipe systems. It features a black EPDM O-ring and stainless steel gripper ring that the pressing tool compresses to form a pressure-tight seal without threading. The coupling is intended for fire sprinkler, chilled water, hydronic heating and low-pressure steam systems and may be installed underground.

• Carbon steel BenchPress coupling with press x press connections for 1-1/4-inch black iron pipe; repair (no stop) straight size design.
• Black EPDM O-ring and stainless steel gripper ring create a pressure-tight seal when compressed by a pressing tool; press connection with no tube stop.
• Certified to IAPMO PS-117 and compliant with NFPA 13/13D/13R, UPC, UMC, and ASME B31; rated up to 200 psi and -20�F to 250�F depending on application.

Product Highlights

BenchPress carbon steel press x press coupling for 1-1/4-inch black iron pipe with EPDM O-ring and stainless gripper; suitable for fire sprinkler, chilled water, hydronic heating and low-pressure steam; IAPMO PS-117 certified.

Product Information

Standard Information

• Brand: NIBCO
• Manufacturer Part Number: PC201 1-1/4

Technical Specifications

• Brand: NIBCO
• Model: PC201
• Manufacturer Part Number: PC201 1-1/4
• Alternate Part Number: 2020550EPC
• Old Material Number: PC201114
• Type: Coupling
• Coupling Type: Repair (No Stop); Straight Size
• Connection Type: Press x Press
• End Connection: Press
• Nominal Pipe Size: 1-1/4"
• Size: 1-1/4"
• Material: Carbon steel
• Weight: 0.934 lb
• Dimensions: 4.460" L x 2.200" W x 2.200" H
• System Use: Fire sprinkler, chilled water, cooling water, hydronic heating, low pressure steam
• Operating Pressure: Up to 200 psi cwp depending on application
• Temperature Range: -20�F to 250�F depending on application
• Certifications: IAPMO PS-117; Complies with NFPA 13, 13D and 13R; Meets IRC and IMC (ICC PMG); Complies with UPC and UMC; Meets ASME B31
• UPC: 039923432889
• Potable Water Code: Not LL Comp not used potable
